SPEED TRIPLE S

If taking on the streets is the name of the game, nothing does it better than the new Triumph Speed Triple S. The new Speed Triple S is more than just a force of nature, it brings unmatched performance, character, style, quality and practicality where it matters – on real roads, in real riding conditions. The aggressive silhouette of the new Speed Triple S houses our acclaimed 1050cc triple engine, tuned to deliver a fist full of linear torque for real-world thrills and top-end performance. It is housed in a chassis engineered for rider engagement and is packed with the latest rider technology. Building on its legend as the original factory street fighter forged 21 years ago, the new Speed Triple S truly has come of age.

SPEED TRIPLE S
  • New triple engine with 104 new components
  • Brembo Monobloc radial calipers
  • DRL headlights
  • Improved peak power and torque spread across entire rev range
  • Ride By Wire
  • Slip-Assist Clutch
  • Switchable ABS
  • Switchable traction control
  • 5 Rider modes
COLOR
ENGINE AND TRANSMISSION
Type

Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder

Capacity

1050 cc

Bore Stroke

79 mm / 71.4 mm

Compression

12.25:1

Max Power EC

140 PS / 138 Bhp (103 kW) @ 9500rpm

Max Torque EC

112 Nm @ 7850rpm

System

Multipoint sequential electronic fuel injection with SAI

Exhaust

Stainless Steel 3 into 1 into 2, twin high level stainless steel silencers

Final drive

X ring chain

Clutch

Wet, multi-plate slip assist cltuch

Gearbox

6-speed

CHASSIS
Frame

Aluminium beam twin-spar

Swingarm

Single-sided, aluminium alloy with eccentric chain adjuster

Front Wheels

Cast aluminium alloy multi-spoke 17 x 3.5 in

Rear Wheels

Cast aluminium alloy multi-spoke 17 x 6.0 in

Front Tyres

120/70 ZR17

Rear Tyres

190/55 ZR17

Front Suspension

Showa 43 mm upside down forks with adjustable rebound and compression damping, 120 mm travel

Rear Suspension

Showa Monoshock with rebound and compression damping, 130 mm rear wheel travel

Brakes Front

Twin 320mm floating discs, Brembo 4-piston 2-pad radial mono-block calipers. Switchable ABS.

Brakes Rear

Single 255 mm disc, Nissin single 2-piston sliding caliper. Switchable ABS.

Instrument Display and Functions

LCD multi-functional instrument pack with digital speedometer, fuel gauge, trip computer, analogue tachometer, lap timer, programmable gear change lights, service interval announcement display, TPMS ready, switchable ABS , Riding Modes setting display

DIMENSIONS AND WEIGHTS
Width Handlebars

780 mm

Height Without Mirror

1070 mm

Seat Height

825 mm

Wheelbase

1435 mm

Rake

22.9º

Trail

91.3 mm

Dry Weight

192 Kg

Tank Capacity

15.5 L

FUEL CONSUMPTION
Fuel Consumption **

5.4 l/100km (52 MPG)

CO2 figures **

EUR0 4 Standard: 119.0 g/km **CO2 and fuel consumption are measured according to regulation 168/2013/EC. Figures on fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.

overview
Max Power EC

140 PS / 138 Bhp (103 kW) @ 9500rpm

Max Torque EC

112 Nm @ 7850rpm

Brakes Front

Twin 320mm floating discs, Brembo 4-piston 2-pad radial mono-block calipers. Switchable ABS.

Brakes Rear

Single 255 mm disc, Nissin single 2-piston sliding caliper. Switchable ABS.

Front Suspension

Showa 43 mm upside down forks with adjustable rebound and compression damping, 120 mm travel

Rear Suspension

Showa Monoshock with rebound and compression damping, 130 mm rear wheel travel
