AD3 200
AD3 SERIES
AD3 perfectly fits ADIVA mission: to offer vehicles with the highest level of SAFETY and PROTECTION
Adiva Advanced Vehicles
AD1 means a great STABILITY and excellent road holding in all weather conditions, SECURITY on all road surfaces, including rail-tracks, pebbles and manholes that may also be found in large cities.
AD3 is equipped with the patented MODULAR PROTECTION SYSTEM. AD3 front suspension, combined with an excellent chassis, ensures an easy and precise turn-in
COLOR
- White
- Graphite
Engine Transmission
Single cylinder four-cycle
72,7 x 72
171,2 cc
21,9kw at 7750 rpm
30.1 Nm at 6250 rpm
Unleaded petrol
Electric Start
Water-cooled
CVT with automatic clutch
Wheels & Frame
Front 130/60 x 13», rear 150/70 x 13» tubeless
5 spokes aluminium rims, front 3.50 x 13», rear 4.00 x 13»
Double 220 mm disc brake
240 mm disc brake
High-resistance steel pipe and traily mixed frame
Single two-ways shock absorber
Engine behaving structural, double rear two-ways shock absorbers preload adjustable on 5 positions
Sizes
2180 mm
700 mm
1759 mm
700 mm
1560 mm
202 kg
12,2 litres (2,0 litres reserve)
